MDF Krone Junction Box 10/20 Pair

MDF Krone Junction Box 10/20 Pair Specification

Product Type
MDF Krone Junction Box

Material
ABS Plastic and Steel

Protection Level
IP54

Surface Treatment
Powder Coated

External Size
Standard 10/20 Pair

Thickness
1.2 mm

Paint Finishing
Powder Coated

Accuracy
High

Dimension (L*W*H)
205 x 190 x 55 mm

Weight
Approx 650 g

Color
Grey

Cable Entry
Bottom/Side Entry

Connection Type
Krone Type Punch Down

Mounting Type
Wall Mounted

Operating Temperature Range
-10C to +60C

Usage/Application
Telecom, Networking, Telephone Distribution

Number of Pairs Supported
10 or 20 Pair

Terminal Strip Material
Phosphor Bronze with Tin Plating

Insulation Resistance
> 1000 M

Standards Compliance
IEC/EN and IS standards certified

Cover Type
Hinged with Screw Lock

Humidity Tolerance
Up to 95% RH

Entry Holes
2 Cable Gland Knockouts

MDF Krone Junction Box 10/20 Pair Trade Information

Minimum Order Quantity
10 Units

Main Domestic Market
Gujarat, Punjab, Delhi, Haryana, Madhya Pradesh, Rajasthan, Uttar Pradesh

About MDF Krone Junction Box 10/20 Pair

The 10/20 Pair MDF Krone Junction Box in Grey color with a smooth Powder Coating surface treatment is made of durable Mild Steel for longevity. This junction box is designed for reliable connectivity and organization of large numbers of wires. The warranty ensures peace of mind for customers relying on this sturdy and secure product.

FAQs of 10/20 Pair MDF Krone Junction Box:

Q: What is the color of the junction box?

A: The color of the junction box is Grey.

Q: What is the surface treatment used on the junction box?

A: The surface treatment used is Powder Coating.

Q: What material is the junction box made of?

A: The junction box is made of Mild Steel.

Q: How is the paint finishing of the junction box described?

A: The paint finishing of the junction box is Smooth.

Q: Is there a warranty provided with the product?

A: Yes, the product comes with a warranty for customer satisfaction.

Superior Connection Reliability

Equipped with Krone type punch down terminals and phosphor bronze strips with tin plating, the MDF Krone Junction Box ensures stable, corrosion-resistant connections for both 10 and 20 pair systems. The high insulation resistance of over 1000 M enhances safety and performance in demanding telecom and networking environments.

Built for Harsh Environments

This junction box is designed to tolerate extreme conditions, operating efficiently from -10C to +60C with humidity levels up to 95% RH. An IP54 protection rating and powder-coated finish safeguard internal components against dust, moisture, and mechanical impacts, ensuring long-term reliability.

FAQ's of MDF Krone Junction Box 10/20 Pair:

Q: How is the MDF Krone Junction Box 10/20 Pair installed?

A: The MDF Krone Junction Box is designed for wall mounting. Its compact dimensions (205 x 190 x 55 mm) and two cable gland knockouts allow for flexible bottom or side cable entry, making it easy to install on various surfaces using standard mounting hardware.

Q: What type of connections does this junction box support?

A: This junction box uses Krone type punch down terminals, which offer secure and reliable connections for either 10 or 20 pairs. The phosphor bronze terminal strips, tin-plated for durability, ensure consistent performance for telecom or networking cables.

Q: When should I use a 10 pair versus a 20 pair configuration?

A: Choose the 10 pair configuration for small-scale applications or low-density networks, and opt for the 20 pair version to support additional lines or higher capacity installations in telecom and telephone distribution environments.

Q: Where is the MDF Krone Junction Box suitable for use?

A: The box can be used in indoor or sheltered outdoor settings, such as telecom closets, office buildings, control rooms, or switchboards. Its IP54 protection makes it ideal for areas exposed to dust and moderate moisture, while the powder-coated finish enhances durability.

Q: What is the process for making connections inside the box?

A: To connect cables, insert them via the bottom or side entry, strip the wires, and use a Krone punch down tool to securely attach them to the designated terminal strips. The hinged cover with a screw lock ensures easy access for technicians while maintaining security.

Q: What are the key benefits of this junction box for telecom installations?

A: This junction box offers high connection reliability, ease of installation, durable materials, IEC/EN and IS certification, and protection from environmental factors. Its versatility makes it suitable for a range of telecom, telephone, and networking distribution systems.
